Precise laser processing systems

DirectLaser MP1 Roll-To-Roll Laser Cutting Equipment For Electronic Metal Materials

New automatic laser cutting system replace corrosion process for making metal precision parts. MP1 laser cutting accuracy is very high and it has no side erosion caused problems. It could provide very good size and shape consistency. With the features of environmentally friendly, flexible process, easy integration into a fully automated continuous production mode, the DirectLaser M1 could be a perfect metal micro processing equipment in the future.


Features

Environmental clean production

Clean production replaces corrosion process

Laser direct structure

Laser cutting and forming fine structure directly

Wide range of applicable

Suitable for stainless steel, copper, aluminum and various alloy materials

Automatic feeding and unloading

Automatic continuous production of coil material, unattended operation

Product parameters

Technical data

DirectLaser MP1

Machinable material

Stainless steel, copper, aluminum

Max. material thickness

3mm

Max. width

400mm

Max.working area

400mm x 400mm

Power requirement

380VAC/16A, 3kW

Dimension(W x H x D)

1,400mm x 1,250mm x 1,550mm

Weight

1,200kg



Configuration and options

DirectLaser MP1

Data processing software

CircuitCAM 7 Pro

Automatic feeding

Optional
